Features
This Neon Strip RGB 24V 840LEDs/m IP67 | Mingxue has the following advantages:
-
Survives Heat and Saturated Humidity
Specified for sauna conditions, it does not cloud, yellow or delaminate the way a general-purpose strip does. That protects the finish the client is paying for.
-
Stays Lit Through the Weather
A sealed, weather-rated build shrugs off dust and water jets, so an outdoor install does not become a recurring maintenance line. The seal does the work a service call would otherwise do.
-
Good flexibility
The corners of the building can also be well sealed. The joints and the ends have all been treated for waterproofing to prevent water from seeping in.
-
OEM/ODM available
The parameters can be customized according to your needs, making your project more manageable and less labor-intensive.
Product Parameters
| Optical parameter | |
|---|---|
| LED Type: | CSP |
| CCT Range: | RGB |
| Beam Angle: | 140° |
| Light Efficiency: | 96 Lm/w |
| Lumen Output: | 559 Lm/m |
| Electric parameter | |
|---|---|
| Input Current: | 0.5 A/m |
| Input Voltage: | DC24V |
| Power: | 12 W/m |
| LEDs/Meter: | 840 |
| Cutting Unit: | 50 mm |
| IP Grade: | IP67 |
Application Scenarios
It can be cut at the marked points every 50 mm. Cutting between those points will disable the section after it, so always trim on the copper pads shown on the tape.
Standard supply is 5 m/reel. Longer and shorter reel lengths, plus pre-terminated leads, can be produced for project orders.
Yes. It is built for sustained high temperature and humidity, using a sleeve and encapsulation that will not cloud or yellow under sauna conditions.
It runs on DC24V constant voltage. Size the driver for the total run length plus headroom, and feed long runs from both ends to keep brightness even.
Yes. It is sealed to IP67 — dust-tight and protected against temporary immersion — so exposed façades, pool surrounds and landscape details are all within scope.
It is supplied at RGB. Other CCTs in the 2700–6500 K range are available on request, with binning held consistent between lots.
It bends in the plane indicated by the profile — side or top depending on the model — and should not be twisted beyond that axis. Our team can confirm the minimum radius for your detail.
This depends on the voltage and power supply method you choose. With a 24V single-ended power supply, the longest connection length is up to 5 meters.
Specifications
-
Chinese Specification Documentpdf3.31MB
-
English Specification Documentpdf2.9MB
